Equipment Info

Digital Storage Oscilloscope

Equipment Info

Equipment Code : 1961582

Make : ROHDE & SCHWARZ

Model : 90304000

Institution : Haldia Institute of Technology (HIT) Haldia

Department : HIT AICTE IDEA LAB

Funding Agency Details : AICTE, Govt. of India

Pooling of Equipment slot : Yes

AMC End Date (Valid Till) :

1 / 2

2 / 2

❮ ❯

PRISM Service Category (About PRISM) : A

Pre-Experiment Support (including sample preparation, setup assistance and pre-experimental guidance) : Yes

Post-Experiment Support (including result interpretation, data analysis and post-experimental reporting) : Yes

Equipment Certification (if any) (View) : Digital Storage Oscilloscope

Equipment Calibration (if any) (View) : Digital Storage Oscilloscope

Remarks / Special Instructions (if any):

Description : Bandwidth : 70 MHz to 300 MHz , Sample Rate : 2 G samples/s , Memory Depth : Upto 20 M , sample : ADC resolution : 10 bit , Display : 10.1" capacitive touch screen , Vertical Scale : 1 mv/Div to 5 V/div with 10 vertical divisions , Timebase accuracy : +/- 2.5 ppm

Usage Rate: (as indicated by the custodian/host institution)

S.No.	Users Category	Rate (unit hour) & (In Rupees)
1	Academic (External)*
2	Academic (Internal)***
3	Grassroot innovator
4	Industry User
5	National Research Lab User
6	Startup/MSME User

Accessories / Consumables / Spare parts / Testing modes

Sample Name	Sample Type	Sample UOM	Sample Availability	Unit Cost	Sample Quantity	Sample Description
No Data Available
